Electrical Characteristics | Nominal Voltage | 60 V |
| Nominal Capacity | 75Ah |
| Energy | 4500Wh |
| Internal Resistance | ≤80mΩ |
| Cycle Life | >2000cycles @1.0C 100%DOD |
| Months Self Discharge | <3% |
| Efficiency of Charge | 100%@0. 2C |
| Efficiency of Discharge | 96~99%@0.5C |
Standard Charge | Charge Voltage | 54.0±0. 1V |
| Charge Mode | 0.2C to 54.0V,then 54.0V,charge current to0.02C(CC/CV) |
| Charge Current | 15A |
| Max. Charge Current | 75A |
| Charge Cut-off Voltage | 57.6V±0. 2 |
Standard Discharge | Continuous Current | 15A |
| Max continuous discharge current | 75A |
| Discharge Cut-off Voltage | 37.5V |
Environmental | Charge Temperature | 0 ºC to 45 ºC (32F to 113F) @60±25% Relative Humidity |
| Discharge Temperature | -20 ºC to 60 ºC (-4F to 140F) @60±25% Relative Humidity |
| Storage Temperature | 0 ºC to 40 ºC (32F to 104F) @60±25% Relative Humidity |
| Water Dust Resistance | IP21 |
Mechanical | Cell & Method | LC-FA027135250-75Ah 15S1P |
| Plastic Case | Iron |
| Dimensions (in./mm.) | 442*400*176mm(17.4"*15.75"*6.93Ins) |
| Weight (lbs./kg.) | Approx:45Kg(99.21Ibs) |
| Gravimetric specific energy | 97WH/KG |
| Protocol (optional) | ModBus/RS485/RS232 |
| SOC (optional) | LED |
Features
1.Longer Cycle Life: Offers up to 20times longer cycle life and
five times longer float /calendar
life than lead acid battery.helping to minimize replacement cost
and reduce total cost of
ownership.
2.Lighter Weight: About 40% of the weight of a comparable lead acid
battery. A 'drop in'
replacement for lead acid batteries.Higher Power: Delivers twice
power of lead acid battery ,
even high discharge rate, while maintaining high energy capacity.
3.Wider Temperature Range: -20C-60C.
4.Superior Safety: Lithium Iron Phosphate chemistry eliminates the
risk of explosion or
combustion due to high impact,overcharging or short circuit
situation.
5.Increased Flexibility: Modular Design enables deployment of up to
four batteries in series
and up to ten battery in parallel.
Applications:
- Passenger and commercial plug-in hybrid electric vehicles (PHEVs)
- Passenger and commercial battery electric vehicles (BEVs)
- Solar power storeing ,e-bike , e scooter, golf cart And Others .
- wildly use battery, model aircraft, electric tools,power tools ,
Golf carts, sightseeing coaches,diy battery pack ,solar energy,
inverters and others
Battery Pack plugs parts avaliable
Any one you want pls kindly contact with us to choose the right one
for you !!!
